Key attributesDescription:
Model Number | ST2401RF |
Application | Hotel/Household Heating Systems |
Design Style | Modern |
Material | ABS+PC Fire Retardant |
Place of Origin | Guangdong, China |
Brand Name | OCSTAT |
Type | Air Conditioning/Heating/HVAC Systems/Radiator/Ventilation/Cooling/Noise and Attenuation/Other/Heating&Cooling |
Backlight | White/Blue/Green |
After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, NONE |
Project Solution Capability | graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE, Others |
Warranty | 2 years |
Specification:
Programmability | Non-Programmable |
System Switch | HEAT/OFF/COOL MODE Switch |
Power Supply | 2 x AAA 1.5V Lithium batteries |
Display accuracy | ±1°C (at 20°C) |
Switchable Voltage | 230 V AC; 50 Hz |
Switchable Current | 8 A (2 A inductive load) |
Temperature Range | 0°C-40°C in 0.1°C |
Setpoint Range | 5°C-35°C in 0.5°C |
Power Consumption | 6W |
Operating Frequency | 868.35 MHz |
Maximum Load | 8(2)A 230VAC Max |
Defrosting Temperature | +7°C |
Operating Principle | Gas Boiler or Water Heating |
Product Description:
1. More than 10 years experience of designing and making room thermostat
2. OEM/ODM service available
3. Quality up to CE, R&TTE, FCC, UL and CSA
4. Competitive price
